HELIX 5 DI G2 FishfinderThe HELIX 5 DI G2 with an improved user interface and operating system, features a brilliant 800H x 480V, 5" 256 color display with backlight. Down Imaging and DualBeam PLUS sonar with 4000 watts PTP power output. Maximize your angling experience with the Humminbird HELIX 5 DI fishfinder system.CHIRP Frequencies (Out of Box Transducer)455 kHz: 420-520 kHz800 kHz: 790-850 kHzMaximum Depth: 600 feetDOWN IMAGING SONARDown Imaging Sonar -- Get a fish-eye's view of what's happening below your boat. Incredible images are created with High-frequency sound waves.SWITCHFIRESwitchFire Sonar -- Take command of how your sonar returns appear with our Clear and Max Modes.DUALBEAM PLUS SONARTwo beams combine for great detail and a wide coverage area. Use the narrow beam for high-accuracy returns and bottom. Use the wide beam when you want a larger search area.UPGRADEABLE SOFTWAREUp-gradable Software -- Access software updates to enhance the performance of your Humminbird unit through our My Humminbird section of the site.WARNING: This product can expose you to chemicals including 1,3-Butadiene which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:
Included Transducer: XNT-9-DI-T
Screen Size: 5"
Transducer Type: Transom Mount
Transducer Included: Yes
Box Dimensions: 5"H x 10"W x 16"L WT: 4 lbs
UPC: 082324049019
Quick Guide (pdf)Owner's Manual (pdf)
HELIX 5 Sonar G2The HELIX 5 Sonar G2 with an improved user interface and operating system, features a brilliant 800H x 480V, 5" 256 color display with backlight. DualBeam PLUS sonar with 4000 watts PTP power output. Maximize your angling experience with the Humminbird HELIX 5 Sonar G2 fishfinder system.WARNING: This product can expose you to chemicals including 1,3-Butadiene which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:
Included Transducer: XNT-9-20T
Screen Size: 5"
Transducer Type: Transom Mount
Transducer Included: Yes
Box Dimensions: 5"H x 10"W x 16"L WT: 3.6 lbs
UPC: 082324048999
Quick Guide (pdf)Owner's Manual (pdf)
HELIX 7 CHIRP MEGA DI GPS G4The HELIX 7 CHIRP MEGA DI GPS G4 fishfinder features MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish. Features:
Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions.
MEGA Down Imaging: Get unprecedented underwater clarity with coverage down to 125 feet below your boat. You'll unlock new details with up to 3X more detail than standard Down Imaging sonar.
Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.
Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.
AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity.
Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.
1-Year Limited Warranty
Specifications:
Display Size - Diagonal: 7"
Display Pixel Matrix: 1024H x 600V
Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging
Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP
CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz)
Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
Depth-Sonar: 1,200 ft (standard transducer), 3,500 ft (optional 50 kHz)
Specifications:
Cartography Brand: Humminbird/Navionics
Included Transducer: XNT-9-HW-MDI-75-T
Screen Size: 7"
Touchscreen: No
Transducer Included: Yes
Box Dimensions: 5"H x 14"W x 17"L WT: 5.3 lbs
UPC: 082324056147
Quick Guide (pdf)Owner's Manual (pdf)
HELIX 7 CHIRP MEGA DI GPS G4N CHOThe HELIX 7 CHIRP MEGA DI GPS G4N CHO fish finder features MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish. All HELIX 7 G4N models support Ethernet networking, Bluetooth(R), NMEA 2000(R), Wi-Fi, and are compatible with the One-Boat Network(TM), which means you'll have total control of your fishing machine at your fingertips.Features:
Control Head Only Model: This model does not include a transducer. This CHO model is a great choice for those looking to connect to Built-in MEGA Down Imaging or Universal Sonar 2 on Minn Kota trolling motors or add to an existing Humminbird Ethernet network.
Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions.
MEGA Down Imaging: Get unprecedented underwater clarity with coverage down to 125 feet below your boat. You'll unlock new details with up to 3X more detail than standard Down Imaging sonar.
Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.
Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.
AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity.
One-Boat Network Compatible: These Humminbird models seamlessly integrate and communicate with other Humminbird and Minn Kota products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.
Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.
Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors. Additional features include wireless software updates from the Humminbird FishSmart App and a display of smartphone notifications on your Humminbird.
NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.
Includes control head, power cable, gimbal mounting bracket, and mounting hardware.
1-Year Limited Warranty
Specifications:
Display Size - Diagonal: 7"
Display Pixel Matrix: 1024H x 600V
Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging
Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP
CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz)
Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
Depth-Sonar: 1,200 ft (standard transducer), 3,500 ft (optional 50 kHz)
Specifications:
Cartography Brand: Humminbird/Navionics
Screen Size: 7"
Touchscreen: No
Transducer Included: No
Box Dimensions: 5"H x 14"W x 17"L WT: 4.6 lbs
UPC: 082324056222
Quick Guide (pdf)Owner's Manual (pdf)
HELIX 7 CHIRP MEGA DI GPS G4NThe HELIX 7 CHIRP MEGA DI GPS G4N fish finder features MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish. All HELIX 7 G4N models support Ethernet networking, Bluetooth(R), NMEA 2000(R), Wi-Fi, and are compatible with the One-Boat Network(TM), which means you'll have total control of your fishing machine at your fingertips. Features:
Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions.
MEGA Down Imaging: Get unprecedented underwater clarity with coverage down to 125 feet below your boat. You'll unlock new details with up to 3X more detail than standard Down Imaging sonar.
Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.
Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.
AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity.
One-Boat Network Compatible: These Humminbird models seamlessly integrate and communicate with other Humminbird and Minn Kota products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.
Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.
Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors. Additional features include wireless software updates from the Humminbird FishSmart App and a display of smartphone notifications on your Humminbird.
NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.
Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.
1-Year Limited Warranty
Specifications:
Display Size - Diagonal: 7"
Display Pixel Matrix: 1024H x 600V
Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging
Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP
CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz)
Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
Depth-Sonar: 1,200 ft (standard transducer), 3,500 ft (optional 50 kHz)
Specifications:
Cartography Brand: Humminbird/Navionics
Included Transducer: XNT-9-HW-MDI-75-T
Screen Size: 7"
Touchscreen: No
Transducer Included: Yes
Box Dimensions: 5"H x 14"W x 17"L WT: 5.65 lbs
UPC: 082324056239
Quick Guide (pdf)Owner's Manual (pdf)
HELIX 7 GPS CHIRP MSI G4The HELIX 7 MEGA SI GPS G4 fish finder features MEGA Side Imaging, MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options, so users never miss a fish.Features:
Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any condition.
MEGA Side Imaging: See the world below like never before with crystal-clear viewing out to 125 feet on either side of the boat. Users unlock new details with up to 3X more detail than standard Side Imaging sonar.
MEGA Down Imaging: Get unprecedented underwater clarity with coverage down to 125 feet below your boat. Unlock new details with up to 3X more detail than standard Down Imaging sonar.
Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.
Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.
AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity.
Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.
1-Year Limited Warranty
Specifications:
Display Size - Diagonal: 7"
Display Pixel Matrix: 1024H x 600V
Transducer Included: XNT 9 HW MSI 150 T
Compatible With: Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, AIS, AutoPilot
Features: Down Imaging, Built-In GPS, Side Imaging, Dual Spectrum CHIRP, Built In Mapping, MEGA Imaging
Memory Card Slot: Single Micro SD
Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging, MEGA Side Imaging
Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP
CHIRP - Frequencies Supported: Narrow Mode (180-240 kHz), 83/200 (75-155/130-250 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz)
Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
Depth-Sonar: 3,500' (optional 50 kHz), 1,200 ft (standard transducer)
CHIRP - Imaging Frequencies Supported: 455 kHz (440-500 kHz), MEGA SI (1075-1150 kHz), MEGA DI (1075-1150 kHz)
Depth-Down Imaging: 75 ft (MEGA), 400 ft (455 kHz)
Range-Side Imaging (Side-To-Side): 800 ft (455 kHz), 250 ft (MEGA)
Interface: Keypad Control
Power Draw: 800 mA
Power Input: 10.8-20 VDC
Power Output Peak-to-Peak: 4000 Watts
Power Output RMS: 500 Watts
Screen Snap Shot: Included
Sonar Recording: Included
Mount-Standard: Gimbal
Mount-Standard Size: 10.54 in W x 5.8 in H x 3.68 in D
Mount-Optional: In-Dash Mounting Kit
Mount-Optional Size: 10.54 in W x 5.44 in H x 1.13 in D
Transducer Mount Location: Transom
GPS Chartplotting: Included
GPS Receiver: Internal
GPS Trackplotting: Included
Waypoints, Routes, Tracks/Points: 2,750, 47, 50/20,000
360 Imaging Compatibility: No
MEGA Live Compatibility: No
Humminbird Basemap: Included
LakeMaster Compatibility: Yes
CoastMaster Compatibility: Yes
Navionics Gold/HotMaps Compatibility: Yes
Navionics Platinum+ Compatibility: Yes
Platinum Compatibility: Yes
Minn Kota i-Pilot Link Compatibility: No
Minn Kota Talon Shallow Water Anchor Compatibility: No
Radar Compatibility: No
5-Port Ethernet Switch Compatibility: No
AIS Compatibility: Optional
Autopilot Compatibility: Yes
Heading Sensor GPS Compatibility: Yes
Target Separation: 2.5"
Interference Rejection: 6 Modes
Noise Rejection: 10 Steps
Upgradable Software: Yes
View Preset Keys: No
X-Press Menu System: Yes
Custom Digital Readout: Yes
Custom View Selections: No
Display Colors Grayscale: 16-Bit
Display Type: Color TFT
Speed: Included
Temperature: Built In
Temperature Alarm: Yes
Temperature Graph: Yes
HDMI Compatible: No
Warranty: One-Year Warranty
Specifications:
Cartography Brand: Humminbird/Navionics
Included Transducer: XNT-9-HW-MSI-150-T
Screen Size: 7"
Touchscreen: No
Transducer Included: Yes
Box Dimensions: 5"H x 14"W x 17"L WT: 5.2 lbs
UPC: 082324058295
Owner's Manual (pdf)
Helix 7 GPS Chirp MSI G4NThe HELIX 7 MEGA SI GPS G4N fish finder features MEGA Side Imaging, MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split-screen view options so that you'll never miss a fish. All HELIX 7 G4N models support Ethernet networking, Bluetooth(R), NMEA 2000(R), and are compatible with the One-Boat Network(TM), which means you'll have total control of your fishing machine at your fingertips.Keypad ControlMaster HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions.CHIRP Side ImagingFilter out noise and clutter for a clearer view of the world below and out to each side of your boat. CHIRP Digital Sonar processing of Side Imaging sonar means that you'll see fish and structure to the left and right of your boat.CHIRP Down ImagingFilter out noise and clutter for a clear view beneath your boat. CHIRP Digital Sonar processing of Down Imaging sonar means that you'll see great detail to make finding the fish simple and easy.Dual Spectrum CHIRP SonarSee what's down there thanks to highly detailed fish arches and a clear view of fish-holding structure and the bottom. Powered by our proprietary Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search: Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.Internal GPS and Humminbird BasemapOur enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.Premium Chart CompatibleGet a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.AutoChart LiveCreate real-time maps of your fishing spots with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity.Specifications
Display Size: 7"
Length: 3.08"
Height: 5.44"
Memory Card Slot: Dual Micro SD
Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging, MEGA Side Imaging
Width: 10.54"
Display Pixel: 1024h x 600v
Included Transducer: XNT 9 HW MSI 150 T
Specifications:
Cartography Brand: Humminbird/Navionics
Included Transducer: XNT-9-HW-MSI-150-T
Screen Size: 7"
Touchscreen: No
Transducer Included: Yes
Box Dimensions: 5"H x 14"W x 17"L WT: 5.6 lbs
UPC: 082324058172
HELIX 7 GPS CHIRP SI G4The HELIX 7 SI GPS G4 fish finder features CHIRP Side Imaging, CHIRP Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish. Features:
Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any condition.
CHIRP Down Imaging: Filter out noise and clutter for a clear view beneath your boat. CHIRP Digital Sonar processing of Down Imaging sonar means that you'll see great detail to make finding the fish simple and easy.
Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.
Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.
AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity.
Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.
1-Year Limited Warranty
Specifications:
Display Size - Diagonal: 7"
Display Pixel Matrix: 1024H x 600V
Transducer Included: XNT 9 HW SI T
Compatible With: Minn Kota US2 Sonar, AIS, AutoPilot
Features: Down Imaging, Built-In GPS, Side Imaging, Dual Spectrum CHIRP, Built In Mapping
Memory Card Slot: Single Micro SD
Sonar-Standard: Dual Spectrum CHIRP, CHIRP Down Imaging, CHIRP Side Imaging
Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP
Live Sonar-Coverage: 20 degrees x 120 degrees
CHIRP - Frequencies Supported: Narrow Mode (180-240 kHz), 83/200 (75-155/130-250 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz)
Sonar-Frequencies Supported: 50/83/200/455 kHz
Depth-Sonar: 3,500' (optional 50 kHz), 1,200 ft (standard transducer)
CHIRP - Imaging Frequencies Supported: 455 kHz (420-520 kHz)
Depth-Down Imaging: 400 ft (455 kHz)
Range-Side Imaging (Side-To-Side): 800 ft (455 kHz)
Interface: Keypad Control
Power Draw: 800 mA
Power Input: 10.8-20 VDC
Power Output Peak-to-Peak: 4000 Watts
Power Output RMS: 500 Watts
Screen Snap Shot: Included
Sonar Recording: Included
Mount-Standard: Gimbal
Mount-Standard Size: 10.54 in W x 5.8 in H x 3.68 in D
Mount-Optional: In-Dash Mounting Kit
Mount-Optional Size: 10.54 in W x 5.44 in H x 1.13 in D
Transducer Mount Location: Transom
GPS Chartplotting: Included
GPS Receiver: Internal
GPS Trackplotting: Included
Waypoints, Routes, Tracks/Points: 2,750, 45, 50/20,000
Humminbird Basemap: Included
LakeMaster Compatibility: Yes
CoastMaster Compatibility: Yes
Navionics Gold/HotMaps Compatibility: Yes
Navionics Platinum+ Compatibility: Yes
Platinum Compatibility: Yes
AIS Compatibility: Optional
Autopilot Compatibility: Yes
Heading Sensor GPS Compatibility: Yes
Target Separation: 2.5"
Interference Rejection: 6 Modes
Noise Rejection: 10 Steps
Upgradable Software: Yes
X-Press Menu System: Yes
Custom Digital Readout: Yes
Display Colors Grayscale: 16-Bit
Display Type: Color TFT
Speed: Included
Temperature: Built In
Temperature Alarm: Yes
Temperature Graph: Yes
Warranty: One-Year Warranty
Specifications:
Cartography Brand: Humminbird/Navionics
Included Transducer: XNT-9-HW-SI-T
Screen Size: 7"
Touchscreen: No
Transducer Included: Yes
Box Dimensions: 5"H x 14"W x 17"L WT: 5.4 lbs
UPC: 082324058288
Owner's Manual (pdf)
ICE Adapter Kit - MEGA 360The MEGA 360 ICE Adapter includes all the components needed to convert a MEGA 360 Imaging transducer for use while ICE fishing. Features:
Compatible with: MEGA 360 Imaging – Ultrex, MEGA 360 Imaging – Fortrex, MEGA 360 Imaging – Universal, MEGA 360 Imaging – No Mount
What’s Included: 10" base, handle, adjustable depth collar, Heading Sensor GPS Puck, and custom power, transducer, and y cables
1-Year Limited Warranty
Quick Guide (pdf)
ICE Adapter Kit - MEGA LiveThe MEGA Live ICE Adapter includes all the components needed to convert a MEGA Live Imaging transducer for use while ICE fishing. Features:
Compatible with: MEGA Live Imaging
Multi-piece pole breaks down into three sections for varying ice depths and a more compact footprint for storage.
What’s Included: Shaft, 10" base, handle, adjustable depth collar, and custom power and ethernet cables
1-Year Limited Warranty
ICE Adapter Kit for MEGA LiveThe MEGA Live ICE Adapter includes all the components needed to convert a MEGA Live Imaging transducer for use while ICE fishing. Features:
Compatible with: MEGA Live Imaging
What’s Included: Shaft, 10" base, handle, adjustable depth collar, and custom power and ethernet cables.
1-Year Limited Warranty
Quick Guide (pdf)
ICE Fishing Flasher Soft-Sided Carrying Case Soft-sided carrying case. (No shuttle, battery, or charger)WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)
ICE PTC UNB Portable Conversion Kit with XI 9 20 Transducer for Non-CHIRPThe ICE PTC XI 9 20 H57 is a portable ice fishing kit for Humminbird HELIX 5 and HELIX 7 models without CHIRP sonar technology. Convert your HELIX 5 or 7 models for ice fishing with the included accessories: portable shuttle with carrying handle, premium Humminbird bag, Dual Beam ice transducer with float, gimbal mounting brackets, HELIX power cable, and installation hardware. This kit will require a battery and charger to operate the HELIX fish finder (sold separately). Kit Includes:
Portable shuttle with carrying handle
premium bag
Dual Beam ice transducer with float
gimbal mounting bracket f/ Helix 5" and 7" Units
HELIX power cable
installation hardware
WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Brochure (pdf)
Ice Xplore 9" Mega Live 2 BundleTake your ice fishing to the next level with the ICE XPLORE + MEGA Live 2 Bundle, delivering next-gen clarity, helping anglers catch more fish, and enjoying every moment on the ice. Built for hardwater, this bundle delivers unmatched clarity, precision, and control beneath the ice. The XPLORE Series fish finder combines a vivid touchscreen display with intuitive mapping and sonar features, while the MEGA Live 2 provides real-time sonar imaging so you can see fish, structure, and lure action in incredible detail. Outfitted with right-sized, cold-weather-ready cables and accessories tailored for ice fishing, this bundle is ready to hit the ice when you are. Note: third-party ice shuttle and pole required for setup.
Next-Gen Clarity: XPLORE Series and MEGA Live 2 deliver ultra-detailed views in real-time, making it easier to find and stay on fish.
Designed for Ice: Includes ice-specific cable lengths, inline fuses, and connectors for hassle-free setup and reliability in cold conditions.
Ice Mode: Streamlined features and functionality for a custom ice experience. Flip back to Open Water Mode when it’s time to move your XPLORE and MEGA Live 2 to your boat.
Real-Time MEGA Live 2 Sonar: Watch fish move, react, and strike your lure with the next-gen clarity of MEGA Live 2 in Forward or Down Mode, now with real-time zoom.
Lakemaster Mapping Included: Ice Xplore fish finders come with LakeMaster® mapping with features like SmartStrike® to keep you on the fish.
Custom Bundle: Pre-matched components streamline compatibility and installation, ready for your choice of ice shuttle and pole for full on-ice functionality.
Warranty: Ice XPLORE carries a 2-year limited warranty, while MEGA Live 2 is covered by a 1-year Warranty.
Included Components: XPLORE fish finder; 18” Power cable with spade connectors and inline fuse; Premium Silicone cover; Gimbal bracket; XPLORE Map Card, MEGA Live 2 Transducer; Compact Pole-mount; 5' Ethernet Cable, 4' Power cable with spade connectors and inline fuse
Specifications:
Transducer Included: MEGA Live Imaging
Compatible With: Minn Kota US2 Sonar, Minn Kota i-Pilot Link, Radar, One-Boat Network, MEGA Live 2
Memory Card Slot: Dual Micro SD
Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional: 50/83/200 kHz, Airmar High, High Wide, Medium, Medium Wide, and Low
Live Sonar-Coverage: 20 degrees x 120 degrees
Interface: Touch Screen, Keypad Control
360 Imaging Compatibility: Yes
MEGA Live Compatibility: Yes
Humminbird Basemap: Included
LakeMaster Compatibility: Yes
CoastMaster Compatibility: Yes
Navionics Gold/HotMaps Compatibility: Yes
Navionics Platinum+ Compatibility: Yes
Platinum Compatibility: Yes
Minn Kota Advanced GPS Navigation Compatibility: Yes
Minn Kota i-Pilot Link Compatibility: Yes
Minn Kota Talon Shallow Water Anchor Compatibility: Yes
Radar Compatibility: Yes
5-Port Ethernet Switch Compatibility: Yes
AIS Compatibility: Optional
Autopilot Compatibility: No
Heading Sensor GPS Compatibility: No
Heading Sensor GPS (NMEA 2000) Compatibility: Yes
NMEA2000: Included
Target Separation: 2.5 in
Upgradable Software: Yes
View Preset Keys: Yes
X-Press Menu System: Yes
Custom Digital Readout: Yes
Custom View Selections: Yes
Display Colors Grayscale: 24-Bit
Display Type: Color TFT
Speed: Included
Temperature: Built In
Temperature Alarm: Yes
Temperature Graph: Yes
HDMI Compatible: No
Specifications:
Cartography Brand: Humminbird/Navionics
Included Transducer: XI-14-HW
Screen Size: 9"
Touchscreen: Yes
Transducer Included: Yes
Box Dimensions: 11"H x 11"W x 16"L WT: 13 lbs
UPC: 082324061424
Quick Guide (pdf)Owner's Manual (pdf)
IDMK H7R2 In-Dash Mounting Kit for HELIX 7 G4The IDMK H7R2 is a rigid and reinforced in-dash mounting kit for HELIX 7 Series fish finders, complete with bracket and hardware. This provides a secure and finished look for the in-dash mounting of your Humminbird fishfinder.Compatible with:HELIX 7 G4 and G4N modelsIn the Box:
Mounting kit
Mounting hardware
*Sold as an Individual Specifications:
Type: Mounting Brackets
Box Dimensions: 3"H x 7"W x 12"L WT: 0.9 lbs
UPC: 082324056444
IDMK X10 XPLORE 10 In-Dash Mounting BracketIn-dash mounting kit for the Humminbird XPLORE Series fish finder is made with rugged, high-strength aluminum for a quick and easy install. This kit includes mounting hardware.Features:
Allows for quick and easy in-dash installation
Rugged, high-strength aluminum design
Contains all necessary mounting hardware
1-Year Limited Warranty
IDMK X12 XPLORE 12 In-Dash Mounting BracketIn-dash mounting kit for the Humminbird XPLORE Series fish finder is made with rugged, high-strength aluminum for a quick and easy install. This kit includes mounting hardware.Features:
Allows for quick and easy in-dash installation
Rugged, high-strength aluminum design
Contains all necessary mounting hardware
1-Year Limited Warranty
IDMK X9 XPLORE 9 In-Dash Mounting BracketIn-dash mounting kit for the Humminbird XPLORE Series fish finder is made with rugged, high-strength aluminum for a quick and easy install. This kit includes mounting hardware.Features:
Allows for quick and easy in-dash installation
Rugged, high-strength aluminum design
Contains all necessary mounting hardware
1-Year Limited Warranty
IMDK H5 In Dash Mounting Kit for HELIX 5 SeriesThe IDMK H5 is an in-dash mounting kit for HELIX 5 model fish finders. This provides what is needed to complete a secure and finished look for in-dash mounting of your Humminbird fish finder.
Compatible with: All HELIX 5 models
This optional in-dash mounting kit is not optimized for metal dash scenarios
1-Year Limited Warranty
WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:
Type: Mounting Brackets
Box Dimensions: 2"H x 8"W x 9"L WT: 0.3 lbs
UPC: 082324045929
Quick Guide (pdf)
LakeMaster® VX - Dakotas/NebraskaAn upgraded mapping solution in Humminbird LakeMaster VX to help anglers understand what is under the water’s surface better than ever before.For decades, Humminbird LakeMaster® has led the charge with the most accurate and advanced mapping available for anglers. Now, LakeMaster is taking it to an entirely new level with the introduction of Humminbird LakeMaster maps with VX Technology.The LakeMaster name has been praised among anglers for having the highest quality mapping for fishing, often collected by a team of GIS analyst cartographers. Now with VX Technology, LakeMaster maps are packed with more information than ever before, including five new customizable color palettes, exceptional map performance, and a powerful combination of features.The LakeMaster lineup maintains the same regions as the current lineup, but now includes SmartStrike technology as a feature, allowing anglers to enter search parameters like season, time of day, temperature, and targeted fish species to create a custom chart that highlights areas of the map where fish are most likely to be biting. LakeMaster also includes customizable Chart Presets, Depth Highlight, Shallow Water Highlight, Water Level Offset, and One-Boat Network capability. LakeMaster has been the go-to road map for anglers, and compared to the competition, what you see on the map is actually on the lake bottom. With LakeMaster with VX Technology, Humminbird LakeMaster solidifies its place as the most accurate and detailed fishing map on the market.Features:
VX Technology – Provides exceptional map performance and customizable color palettes.
SmartStrike – Highlights areas of the lake map where fish are most likely biting. (*Select HD Lakes Only)
Chart Presets – Simple and easy to change between your own custom view settings.
Depth Highlight – Highlight a selected depth range so you can target productive water and stay where the fish are.
Shallow Water Highlight – Easy-to-see red shading highlights shallow water areas on an adjustable range from 0 to 60 feet.
Water Level Offset – Synchronize the depth contours and shorelines of your LakeMaster charts with the actual water levels of lakes, reservoirs and rivers.
One-Boat Network – Connects your Humminbird LakeMaster chart and Minn Kota trolling motor, allowing your boat to automatically follow a depth contour line.
Compatible with Humminbird HELIX® G3/G3N and newer, all SOLIX® units and all APEX™ units.
1-Year Cartography Warranty. Opened packages are not eligible for return.
Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)
LakeMaster® VX - Great LakesAn upgraded mapping solution in Humminbird LakeMaster VX to help anglers understand what is under the water’s surface better than ever before.For decades, Humminbird LakeMaster® has led the charge with the most accurate and advanced mapping available for anglers. Now, LakeMaster is taking it to an entirely new level with the introduction of Humminbird LakeMaster maps with VX Technology.The LakeMaster name has been praised among anglers for having the highest quality mapping for fishing, often collected by a team of GIS analyst cartographers. Now with VX Technology, LakeMaster maps are packed with more information than ever before, including five new customizable color palettes, exceptional map performance, and a powerful combination of features.The LakeMaster lineup maintains the same regions as the current lineup, but now includes SmartStrike technology as a feature, allowing anglers to enter search parameters like season, time of day, temperature, and targeted fish species to create a custom chart that highlights areas of the map where fish are most likely to be biting. LakeMaster also includes customizable Chart Presets, Depth Highlight, Shallow Water Highlight, Water Level Offset, and One-Boat Network capability. LakeMaster has been the go-to road map for anglers, and compared to the competition, what you see on the map is actually on the lake bottom. With LakeMaster with VX Technology, Humminbird LakeMaster solidifies its place as the most accurate and detailed fishing map on the market.Features:
VX Technology – Provides exceptional map performance and customizable color palettes.
SmartStrike – Highlights areas of the lake map where fish are most likely biting. (*Select HD Lakes Only)
Chart Presets – Simple and easy to change between your own custom view settings.
Depth Highlight – Highlight a selected depth range so you can target productive water and stay where the fish are.
Shallow Water Highlight – Easy-to-see red shading highlights shallow water areas on an adjustable range from 0 to 60 feet.
Water Level Offset – Synchronize the depth contours and shorelines of your LakeMaster charts with the actual water levels of lakes, reservoirs and rivers.
One-Boat Network – Connects your Humminbird LakeMaster chart and Minn Kota trolling motor, allowing your boat to automatically follow a depth contour line.
Compatible with Humminbird HELIX® G3/G3N and newer, all SOLIX® units and all APEX™ units.
1-Year Cartography Warranty. Opened packages are not eligible for return.
Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)
LakeMaster® VX - Great PlainsAn upgraded mapping solution in Humminbird LakeMaster VX to help anglers understand what is under the water’s surface better than ever before.For decades, Humminbird LakeMaster® has led the charge with the most accurate and advanced mapping available for anglers. Now, LakeMaster is taking it to an entirely new level with the introduction of Humminbird LakeMaster maps with VX Technology.The LakeMaster name has been praised among anglers for having the highest quality mapping for fishing, often collected by a team of GIS analyst cartographers. Now with VX Technology, LakeMaster maps are packed with more information than ever before, including five new customizable color palettes, exceptional map performance, and a powerful combination of features.The LakeMaster lineup maintains the same regions as the current lineup, but now includes SmartStrike technology as a feature, allowing anglers to enter search parameters like season, time of day, temperature, and targeted fish species to create a custom chart that highlights areas of the map where fish are most likely to be biting. LakeMaster also includes customizable Chart Presets, Depth Highlight, Shallow Water Highlight, Water Level Offset, and One-Boat Network capability. LakeMaster has been the go-to road map for anglers, and compared to the competition, what you see on the map is actually on the lake bottom. With LakeMaster with VX Technology, Humminbird LakeMaster solidifies its place as the most accurate and detailed fishing map on the market.Features:
VX Technology – Provides exceptional map performance and customizable color palettes.
SmartStrike – Highlights areas of the lake map where fish are most likely biting. (*Select HD Lakes Only)
Chart Presets – Simple and easy to change between your own custom view settings.
Depth Highlight – Highlight a selected depth range so you can target productive water and stay where the fish are.
Shallow Water Highlight – Easy-to-see red shading highlights shallow water areas on an adjustable range from 0 to 60 feet.
Water Level Offset – Synchronize the depth contours and shorelines of your LakeMaster charts with the actual water levels of lakes, reservoirs and rivers.
One-Boat Network – Connects your Humminbird LakeMaster chart and Minn Kota trolling motor, allowing your boat to automatically follow a depth contour line.
Compatible with Humminbird HELIX® G3/G3N and newer, all SOLIX® units and all APEX™ units.
1-Year Cartography Warranty. Opened packages are not eligible for return.
Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)
LakeMaster® VX - Mid-South StatesAn upgraded mapping solution in Humminbird LakeMaster VX to help anglers understand what is under the water’s surface better than ever before.For decades, Humminbird LakeMaster® has led the charge with the most accurate and advanced mapping available for anglers. Now, LakeMaster is taking it to an entirely new level with the introduction of Humminbird LakeMaster maps with VX Technology.The LakeMaster name has been praised among anglers for having the highest quality mapping for fishing, often collected by a team of GIS analyst cartographers. Now with VX Technology, LakeMaster maps are packed with more information than ever before, including five new customizable color palettes, exceptional map performance, and a powerful combination of features.The LakeMaster lineup maintains the same regions as the current lineup, but now includes SmartStrike technology as a feature, allowing anglers to enter search parameters like season, time of day, temperature, and targeted fish species to create a custom chart that highlights areas of the map where fish are most likely to be biting. LakeMaster also includes customizable Chart Presets, Depth Highlight, Shallow Water Highlight, Water Level Offset, and One-Boat Network capability. LakeMaster has been the go-to road map for anglers, and compared to the competition, what you see on the map is actually on the lake bottom. With LakeMaster with VX Technology, Humminbird LakeMaster solidifies its place as the most accurate and detailed fishing map on the market.Features:
VX Technology – Provides exceptional map performance and customizable color palettes.
SmartStrike – Highlights areas of the lake map where fish are most likely biting. (*Select HD Lakes Only)
Chart Presets – Simple and easy to change between your own custom view settings.
Depth Highlight – Highlight a selected depth range so you can target productive water and stay where the fish are.
Shallow Water Highlight – Easy-to-see red shading highlights shallow water areas on an adjustable range from 0 to 60 feet.
Water Level Offset – Synchronize the depth contours and shorelines of your LakeMaster charts with the actual water levels of lakes, reservoirs and rivers.
One-Boat Network – Connects your Humminbird LakeMaster chart and Minn Kota trolling motor, allowing your boat to automatically follow a depth contour line.
Compatible with Humminbird HELIX® G3/G3N and newer, all SOLIX® units and all APEX™ units.
1-Year Cartography Warranty. Opened packages are not eligible for return.
Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)
LakeMaster® VX - MinnesotaAn upgraded mapping solution in Humminbird LakeMaster VX to help anglers understand what is under the water’s surface better than ever before.For decades, Humminbird LakeMaster® has led the charge with the most accurate and advanced mapping available for anglers. Now, LakeMaster is taking it to an entirely new level with the introduction of Humminbird LakeMaster maps with VX Technology.The LakeMaster name has been praised among anglers for having the highest quality mapping for fishing, often collected by a team of GIS analyst cartographers. Now with VX Technology, LakeMaster maps are packed with more information than ever before, including five new customizable color palettes, exceptional map performance, and a powerful combination of features.The LakeMaster lineup maintains the same regions as the current lineup, but now includes SmartStrike technology as a feature, allowing anglers to enter search parameters like season, time of day, temperature, and targeted fish species to create a custom chart that highlights areas of the map where fish are most likely to be biting. LakeMaster also includes customizable Chart Presets, Depth Highlight, Shallow Water Highlight, Water Level Offset, and One-Boat Network capability. LakeMaster has been the go-to road map for anglers, and compared to the competition, what you see on the map is actually on the lake bottom. With LakeMaster with VX Technology, Humminbird LakeMaster solidifies its place as the most accurate and detailed fishing map on the market.Features:
VX Technology – Provides exceptional map performance and customizable color palettes.
SmartStrike – Highlights areas of the lake map where fish are most likely biting. (*Select HD Lakes Only)
Chart Presets – Simple and easy to change between your own custom view settings.
Depth Highlight – Highlight a selected depth range so you can target productive water and stay where the fish are.
Shallow Water Highlight – Easy-to-see red shading highlights shallow water areas on an adjustable range from 0 to 60 feet.
Water Level Offset – Synchronize the depth contours and shorelines of your LakeMaster charts with the actual water levels of lakes, reservoirs and rivers.
One-Boat Network – Connects your Humminbird LakeMaster chart and Minn Kota trolling motor, allowing your boat to automatically follow a depth contour line.
Compatible with Humminbird HELIX® G3/G3N and newer, all SOLIX® units and all APEX™ units.
1-Year Cartography Warranty. Opened packages are not eligible for return.
Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)
